FLAT STRUT FITTINGS

SQUARE WASHERS

POSI-TECH strut square washers are used to secure threaded rod and other singular fastening
requirements. Our washers provide a pos ve lock against channel and channel nuts, ensuring that all
connec ons are secure and stable.
BOLT SIZE DIMENSIONS ELECTRO-GALV 304 STAINLESS 316 STAINLESS

1/4” 1-5/8” x 1-5/8” F100025EG F100025S4 F100025S6
3/8” 1-5/8” x 1-5/8” F110037EG F110037S4 F110037S6
1/2” 1-5/8” x 1-5/8” F120050EG F120050S4 F120050S6

SPLICE PLATES

POSI-TECH splice plates are deisnged to join two lengths of strut channel in-line, end to end. Splice
plates provide a pos ve lock against channel and channel nuts, ensuring that all connec ons are
secure and stable.

DIMENSIONS HOLES ELECTRO-GALV 316 STAINLESS
1-5/8” x 5-3/8”” 3 F310000EG F310000S6
1-5/8” x 7-1/4” 4 F320000EG F320000S6

TEE SPLICE PLATES

POSI-TECH tee splice plates are deisnged to join two lengths of strut channel, crea ng a 90 degree
intersec on. Splice plates provide a pos ve lock against channel and channel nuts, ensuring that all
connec ons are secure and stable.

DIMENSIONS HOLES ELECTRO-GALV
1-5/8” X 5-3/8” X 3-1/2” 4 F600000EG

CORNER SPLICE PLATES

POSI-TECH corner splice plates are deisnged to join two lengths of strut channel, crea ng a 90
degree angle. Splice plates provide a pos ve lock against channel and channel nuts, ensuring that all
connec ons are secure and stable.

DIMENSIONSSIONS HOLESOLES ELECTRO-GALVCTRO-GALV
DIMEN
ELE
H
F510000EG10000EG
1-5/8” X 3-1/2” X 3-1/2”
1-5/8” X 3-1/2” X 3-1/2” 3 3 F5
MADE IN THE USA

Our strut fittings are proudly made in the United States of America with the
highest quality standards. Available in Electro-Galv, 304 and 316 Stainless!
